Window Generator HDA Complete Edition

$149
0 ratings

Use WINDOW GENERATOR COMPLETE HOUDINI DIGITAL ASSET - HDALC to create high quality arch viz, vfx projects, games and more.

This Roller Shutter Generator is an extract of our complete window generator collection, which creates windows and almost everything around it for exteriors and interiors.

Create windows of any size, fully equipped with sun shade for inside and outside. All models are UV mapped and have various options to adjust the poly count. Use high detailed objects for close ups. Decrease the poly count for objects in the background.

OVERVIEW:

WINDOW GENERATOR:

height, width, double wings, glazing bars, open/close, swing/tilt, open side left/right, wing profile size, frame profile size, distance frame wing, uv mapping, offset transform, sill interior/exterior, surrounding interior/exterior, surrounding exterior type: plaster/brick, surrounding size, railing type: glas/wireframe, railing height, wall depth inside/outside, sill exterior type: metal/stone, crown type: triangle/round

MARKISOLETTE GENERATOR exterior:

height/width adjustment, open/close, arms, arm length, slope, box size, rail mounts on/off, uv mapping, front fabric: height, amplitude, frequency, subdivisions, offset transform

ROLLER BLIND GENERATOR exterior:

height/width adjustment, open/close, blade size, blade bend, box type: square/round, uv mapping, offset transform

BASKET AWNING GENERATOR exterior:

height/width adjustment, open/close, fast preview, depth, bevel, elements, bend back/front, nails, uv mapping, front fabric: amplitude, frequency, fringe height, height scale, poly count, offset transform

VENETIAN BLIND GENERATOR exterior:

height/width adjustment, open/close, blade rotation, box height, blade width, blade thickness, blade curve, blade randomness, amount of pull strings, step ladder strings: radius, subdivision, delta zig zag, jitter, uv mapping, offset transform

VENETIAN BLIND GENERATOR interior:

height/width adjustment, open/close, blade rotation, blade width, blade thickness, blade curve, blade randomness, amount of pull strings, step ladder strings: radius, subdivision, delta zig zag, jitter, handling type: chain/string, handling position: left/right, handling height, sphere subdivision, uv mapping, offset transform

PLISSEE GENERATOR interior:

height/width adjustment, open/close, open from top, uv mapping, offset transform

ROLLO GENERATOR interior:

height/width adjustment, open/close, handling type: chain/string, handling position: left/right, handling height, sphere subdivision, uv mapping, offset transform

BAMBOO ROLLO GENERATOR interior:

height/width adjustment, open/close, roll it: rotation/capture length/capture direction, bamboo: size/overshoot/direction/lower bend, amount of pull strings, pull strings inside, handling position: left/right, handling height, fix string collision x/y, uv mapping, offset transform

OFFICE BLIND GENERATOR interior:

height/width adjustment, open/close, fast preview mode, blade width, rotation, construction/animation mode //be aware of the engine limitations - see below//, handling type: chain/string, handling position: left/right, handling height, handling details weight, geometry details: low poly rail/lower string/string subdivision/lower string spheres/sphere amount/sphere subdivision, sack amount/difference, uv mapping, offset transform

JAPANESE BLIND GENERATOR interior:

height/width adjustment, open/close, number of slides, position of slides, uv mapping, offset transform

FLAT AWNING GENERATOR:

depth/width adjustment, open/close, tilt, arm position, fringe on/off, fringe height, waveamplitide, wavelenght, subdiv. arms, winder on/off, winder position: left/right, winder height, winder rotation, uv mapping


INSTALLATION NOTES:

Watch the HOW TO INSTALL THE HOUDINI ENGINE video.

https://www.youtube.com/watch?v=SMc8TvIntI4

You can test the pipeline before you purchase the HDA. Please download:

https://gumroad.com/l/OiUXr

IMPORTANT INFORMATION FOR ANIMATION:

Not every HOUDINI ENGINE supports the animation modes //p.e. UNREAL, UNITY and 3DS MAX// so check the limitations for your host application


UPDATES:
Sept_2021: Flat Awning Generator incl. textures and C4D shader for V-Ray and Corona


We going to release updates for free with bug fixes and new tools. Check and follow our facebook site.



DETAILS:

Created with

Houdini 18 //

The HDA works in Houdini, Maya, Cinema 4d, Unity and Unreal.

AUTODESK 3DS MAX user can apply for a BETA version - drop us a line at WEWILLHELPYOU.

If you need a HDA instead of a HDALC please contact us directly via our website, facebook or instagram.


All elements have clean topology

UV mapped


RECOMMENDED USES:

Architecture visualisation, film asset, game asset, design and many more.


LEGAL STUFF:

None of the content may be redistributed without permission.

We Love Feedback!

We created this product to make your life easier and we want to hear about it.

If this product saves you time creating great VFX work, please share our site and name, give us a like, or write a comment.


Thank you very much & enjoy!

Cheers & Peace,

Your Mellowmesher Team.
